Connection box series
Junction Box
Model:J04
Connects to up to 4 load cells
Individual channel trim potentiometers
Die-cast aluminum housing
Surge and EMI Protection
Compact design for easy installation
Stuffed and un-stuffed entries and exits
Compatible with 350 ohm sensors
Includes internal connection diagram
Product Description
Connection box for multi-sensor weighing systems. Allows connection and adjustment of up to 4 load cells in parallel.
Key Features
Channels 4 sensors
Material Die-cast aluminum
Protection IP65
Impedance 350 ohms
Adjust Individual potentiometers
Temperature -20°C a +60°C
Certification CE, ISO9001
Applications
Platform Scale Systems
Floor scales
Tank weighing systems
Truck Scales
Technical Specifications
| channels | 4 |
| material | Die-Cast Aluminum |
| protection | IP65 |
| impedance | 350 ohms |
| temperature | -20°C a +60°C |
| certification | CE, ISO9001 |
